VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI)

Send Inquiry

Request To Call Back

VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI)

Name: VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI)
Brand: VEGA CALIBRATIONS LLP.
Price: 17699 INR
Availability: InStock

Price 17699 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI) Specification

Temperature Range
-40C to +85C

Theory
Electronic data logging

Alarm
Configurable high/low alarm via mobile application

Power Supply
DC 5V micro USB (rechargeable)

Data Capacity
16000 points (temperature + humidity)

Type
Realtime Temperature And Humidity Data Logger (WIFI)

Display Type
LCD display

Memory
16000 readings (approx)

Accuracy
Temperature: 0.5C, Humidity: 3% RH

Size
Approx. 105 mm x 54 mm x 28 mm

Resolution
Temperature: 0.1C, Humidity: 0.1% RH

Battery
Rechargeable lithium battery 2000mAh

Net Weight
Approx. 120g

Standby Time
Up to 6 months

Interface
WIFI 802.11 b/g/n

Measuring Range
-40C to +85C (Temperature), 0 to 100% RH (Humidity)

Includes
Logger unit, user manual, USB charging cable

Working Temperature
-40°C to +85°C

Humidity Range
0-100% RH

Communication Mode
WIFI with real-time data upload

Compliance
CE, RoHS certified

Calibration
User calibratable via application

Mobile Application
Supported (iOS and Android)

Mounting
Wall mount and desktop options available

Sampling Interval
Configurable from 10 seconds to 18 hours

Enclosure Rating
IP54 - Dust and splash resistant

Data Export
CSV format via mobile application

About VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI)

Brand	VEGA
Model	WTH120
Temperature Range	-40C to +120C
Humidity Range	0% RH to 100% RH
Sensor Type	Temp+RH Sensor
Temperature Accuracy Accuracy	0.5C 3% RH
Resolution	0.1C 0.1% RH
Cloud Storage	3 Month
Internal Data Storage	150 Days (15 min Interval
Display Type	Digital LED Display

VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI) that can measure two different temperatures at the same time, e.g. ambient and refrigerator temperature. It can be used in cold room/ storages, clean rooms in Pharma and food industry.

The Web/Mobile app supports complete Device and User data management with Alerts and Alarms.

Typical Uses:

Refrigeration monitoring and failure detection. Restaurant food safety

Industrial temperature monitoring. Detect freezing temperatures to protect plumbing

Detect heat failure in second homes or remote buildings. General precision temperature sensor. 1.3" 128X64 OLED monochrome Graphical Display

Internal Li-Ion 4000 mAh battery with under/ over protection, up to 72 Hrs battery back-up to mitigate power failure.

Plug & Play Device. WiFi 802.11 b/g/n 2.4 GHz. Internal Storage 150 days at sampling frequency of 15 mins. DC Input Voltage 5V/1A. IP Rated

Alerts, Analytics, Device Management, User Management, Parameter Rules Management. Web/mobile App., Dashboard, Reports, Alerts

Accurate and Flexible Environmental Monitoring

With high-resolution measurements and configurable sampling intervals, the VEGA IoT WTH120 provides precise data for both temperature and humidity in diverse conditions. It is suitable for industries requiring reliable monitoring, including laboratories, warehouses, and manufacturing facilities. Real-time Wi-Fi data upload ensures immediate access to environmental readings from any location.

Seamless Connectivity and Data Management

Easily set up the logger using the mobile application, which supports both iOS and Android devices. Users can remotely monitor data, configure alerts, calibrate the instrument, and export historical records in CSV format-all through an intuitive app interface. Integration with Wi-Fi ensures quick and automatic data synchronization, making compliance and record-keeping effortless.

Durable Design for Demanding Conditions

Boasting an IP54 enclosure and a wide operational temperature and humidity range, the VEGA IoT WTH120 excels in harsh or variable environments. Its compact, lightweight build, flexible mounting choices, and rechargeable battery provide extended, worry-free operation wherever reliable monitoring is needed.

FAQ's of VEGA IoT WTH120 Realtime Temperature And Humidity Data Logger (WIFI):

Q: How do I configure the sampling interval on the VEGA IoT WTH120?

A: The sampling interval can be set between 10 seconds and 18 hours via the mobile application (available for both iOS and Android). Simply connect to the logger through the app, navigate to settings, and select your preferred interval for temperature and humidity data logging.

Q: What are the available options for mounting the data logger?

A: The VEGA IoT WTH120 offers both wall mount and desktop placement options. This flexibility allows users to install the logger in locations best suited for accurate environmental monitoring, whether in industrial, commercial, or laboratory settings.

Q: When should I calibrate the data logger, and how is it done?

A: Calibration can be performed anytime using the mobile application. It is recommended to calibrate the logger periodically or following exposure to extreme environmental changes. The app provides step-by-step instructions to ensure accurate readings.

Q: Where can I access and export the logged data?

A: All logged temperature and humidity records are stored in the device's memory and automatically uploaded in real time via Wi-Fi. Historical data can be viewed and exported in CSV format directly from the mobile app, allowing easy transfer and analysis on your computer.

Q: What benefits does the real-time Wi-Fi data upload provide?

A: Real-time Wi-Fi data upload ensures you always have access to current environmental readings from any location. This immediate data availability supports faster decision-making and compliance monitoring, particularly in dynamic or sensitive environments.

Q: How long does the battery last, and how is it recharged?

A: The logger is equipped with a 2000mAh rechargeable lithium battery that provides up to six months of standby time. It is easily recharged using the included DC 5V micro USB cable, ensuring long-term, low-maintenance operation.
